60cm foil hot stamping UV DTF printer
- Ink type: UV ink
- Printhead: I3200U1 printhead
- Quantity of printhead: 4pcs
- Resolution: 720*1200dpi
- Print width: 650mm
- Humidity: 35% to 80% RH
- Media type: Suit for Leather, advertising, fabrics, Flexible materials
- Machine size: 1850*990*1610mm
- Overview
- Recommended Products
Description
This 60cm Foil Hot Stamping UV DTF printer is equipped with 4pcs i3200-U1 print heads, which significantly increase the amount of ink droplets ejected through piezoelectric inkjet technology. Not only does it greatly improve printing efficiency, but it also optimizes the lines, color transitions, and text clarity of patterns.
Our machines are equipped with Hoson board (have a one-year free warranty), genuine Maintop software, and we also provide one-year online after-sales technical guidance service.
The 60cm foil hot stamping all-in-one machine, with advanced hot pressing technology, can accurately control the hot stamping temperature, pressure, and time. Whether it's complex and exquisite patterns or clear and sharp text markings, they can perfectly present a full and shiny hot stamping effect on various material surfaces. The gold foil adheres firmly and has a long-lasting and bright color, adding a high-end luxury texture to the product and greatly enhancing its grade and visual appeal.
Specifications
Parameter | |
Model |
YQ-600HY |
Ink type |
UV ink |
Printhead |
I3200U1 printhead |
Quantity of printhead |
4pcs |
Resolution |
720*1200dpi |
Print width |
650mm |
Humidity |
35% to 80% RH |
Media type |
Suit for Leather, advertising, fabrics, Flexible materials |
Machine size |
1850*990*1610mm |
Media transmission |
Media feeding system |
Color confgration |
4color (CMYK)+W+V1+V2 |
Print speed |
I3200U1: 7M2/h |
RIP software |
Maintop/Photoprint/R11N/Photo factory |
Input powder supply |
AC220V/110V(±5%),50HZ/60HZ |
Weight |
255kg |
Wooden box packing size |
2004x1140x1530mm |
Applications
Widely used in common materials such as paper, leather, plastic, and fabric, it can intelligently adjust the hot stamping parameters based on different material characteristics (whether it is soft fabric or hard plastic), ensuring a tight fit between the gold foil and the material, achieving excellent hot stamping effect, and can easily cope with it, expanding the application range of the product.
Advantages
( 1 ) Excellent picture quality.
High resolution:
The printed images and text have clear and sharp edges, rich details, and can present both fine patterns and tiny text clearly, meeting the high quality requirements of users.
High color reproduction:
Accurately reproducing the colors of the original image, with high color saturation and appropriate contrast, the printed image is vivid and realistic in color, giving a strong visual impact.
Delicate color transition:
When printing gradient colors or images with rich color tone layers, it can avoid color discontinuity or stripe phenomenon, make color transition natural and smooth, and present a softer and more realistic picture effect.
( 2 ) Efficient homework ability.
Its 60cm wide design allows for a large area to be covered with just one hot stamping, significantly reducing the number of repeated operations during batch production compared to small-sized equipment. At the same time, the equipment has a fast heating and efficient heat conduction system, with fast hot stamping speed. In large-scale production scenarios, it can efficiently complete hot stamping tasks, greatly shorten production cycles, meet the needs of enterprises for efficient shipping, improve production efficiency, and reduce time costs.
( 3 ) Efficient printing.
Faster printing speed:
With the premise of ensuring high-quality printing, it has a relatively fast printing speed. Its printing speed can meet daily production needs and effectively improve work efficiency.
Good stability in continuous printing:
The stable mechanical structure and control system ensure the stability of the printer during long-term continuous printing processes. The key components such as the print head and motor can operate continuously and efficiently, avoiding problems such as overheating and lagging, ensuring the smooth progress of printing tasks, reducing downtime caused by equipment failures, and improving production efficiency.
FAQ
Q：What should I do if the print head of the printer is blocked?
A：The printer is equipped with an automatic cleaning and ink scraping system. When there is a slight blockage in the print head, the automatic cleaning function can be activated through the printer's control panel. This function uses cleaning solution to clean the print head and usually solves the blockage problem. If the blockage still cannot be resolved after automatic cleaning, it may be due to severe blockage of the print head. In this case, we need to contact our after-sales technical personnel for handling. After sales technicians will use more professional cleaning methods, such as soaking and cleaning with specialized print head cleaning solution. It is not recommended for users to disassemble the print head for cleaning on their own to avoid damaging the print head.
Q：Can it be printed on media of different thicknesses?
A：This printer can print on media within a certain thickness range. When printing media of different thicknesses, it is necessary to adjust the relevant parameters of the printer appropriately according to the thickness of the media, such as the height of the print head, pressure, etc., to ensure that the appropriate distance is maintained between the print head and the media, and to ensure the printing effect. The specific adjustment method can refer to the printer's operation manual or consult the after-sales technical personnel.
Q：How long is the warranty period for the printer?
A：In general, the entire printer comes with a one-year warranty service, and core components such as print heads, motors, control systems, etc. are also covered by a one-year warranty. During the warranty period, if the equipment malfunctions due to non-human factors, the manufacturer will provide free repair services. However, it should be noted that users should operate and maintain the equipment correctly according to the printer's user manual, otherwise it may affect warranty rights. If the device exceeds the warranty period, users can still contact after-sales technicians for repairs, but they will need to pay the corresponding repair fees.
